FEATURES

• UL 1069 Listed
• Controls system functions with microprocessor
• All wire terminations are made inside with easy “screwless” wire connections

SPECS
Wire Type:
Sub / Duty Station to Central Control Unit: 4 twisted pair, low cap, PE, overall shield - use Aiphone #862208
Master Station to Central Control Unit: 5 twisted pair, low cap, PE, overall shield - use Aiphone #862210

Distance:
Sub Station to Central Control Unit: 165'(22AWG)
Duty Station to Central Control Unit: 65'(22AWG)
Master Station to Central Control Unit: 65'(22AWG)
Sub Station to Central Control Unit: 165'(22AWG). Max. cumulative wire distance per trunk line: 330'(22AWG).
